YVV(0.5mm2) 儀表用通信電纜的產品介紹:儀表用通信電纜
Product introduction of YVV (0.5mm2) instrument communication cable: Instrument communication cable
1、產品用途：本產品適用于儀表、儀器及其它電器設備中的信號傳輸及控制線路。
1. Product Usage: This product is suitable for signal transmission and control circuits in instruments, apparatus, and other electrical equipment.
2、產品使用特性：電纜的交流額定電壓500V以下，電纜線芯的長期工作溫度應不超過70℃。電纜允許彎曲關徑應不小于電纜外徑的6倍，敷設溫度應不低于0℃。
2. Product usage characteristics: The AC rated voltage of the cable is below 500V, and the long-term working temperature of the cable core should not exceed 70 ℃. The allowable bending diameter of the cable should not be less than 6 times the outer diameter of the cable, and the laying temperature should not be lower than 0 ℃.
3、產品型號、名稱及使用范圍
3. Product model, name, and scope of use
型號 名稱
Model name
使用范圍
Scope of use
YVV 聚氯乙烯絕緣、聚氯乙烯護套儀表用電纜 固定敷設，用于儀器、儀表的連接
YVV PVC insulated and PVC sheathed instrument cables are fixed and laid for the connection of instruments and meters
YVVP 聚氯乙烯絕緣、聚氯乙烯護套儀表用屏蔽電纜 同上，用于要求抗干擾的情況下
YVVP PVC insulated and PVC sheathed shielded cable for instruments, as above, used in situations where anti-interference is required
RVV 聚氯乙烯絕緣、聚氯乙烯護套儀表用軟電纜 用于要求柔軟的場合
RVV PVC insulated and PVC sheathed flexible cables for instruments are used in applications that require flexibility
RVVP 聚氯乙烯絕緣、聚氯乙烯護套儀表用屏蔽軟電纜 同RVV型，用于抗干擾場合
RVVP PVC insulated and PVC sheathed shielded flexible cable for instruments, same as RVV type, used in anti-interference occasions
4、生產范圍
4. Production scope
型號 芯數
Model number of cores
標稱截面(mm2)
Nominal cross-section (mm2)
YVV
YVV
YVVP
YVVP
RVV
RVV
RVVP
RVVP
2、3、4、5、6、7、8、10、12 0.5 0.75 1.0 1.5 2.5
2. 3, 4, 5, 6, 7, 8, 10, 12 0.5 0.75 1.0 1.5 2.5
